- Enhanced magnetic/air damping compensator.
- Excellent shockproof function.
- Practical dustproof & waterproof capability
- high-cost performance and durable
- Ultra-clear lens for long-range observation
- Newly developed magnetic damping compensator
- Reliable performance in extreme temperature
- Excellent shockproof test performance
- Top dustproof and waterproof capability IP65
Auto Level KL-A30 / KL/ DSZ Series
We are amongst the renowned companies in this domain and are involved in presenting a wide range of Kolida Automatic Level to our customers. This Kolida Automatic Level is made in accordance with set market quality standards and norms. Besides, these products are widely used for leveling purpose in construction of roads.
| Model |
KL20 G style |
KL24 G style | KL28 G style | KL32G style | KL-C32 | KL-A32 | KL-Z32 | DSZ2 |
DSZ3 |
| Magnification |
20X |
24X | 28X | 32X | 32X | 32X | 32X | 32X |
28X |
| Effective objective aperture |
34mm |
36mm | 36mm | 38mm | 40mm | 40mm | 45mm | 45mm |
40mm |
| Image |
Erect |
Erect |
Erect |
||||||
| Reticle |
Cross reticle |
Cross reticle |
Cross reticle |
||||||
| Field of View |
1 0 20' (2.3m/100m) |
1 0 20' (2.3m/100m) |
1 0 30 (2.6m/100m) |
||||||
| Minimum focus distance |
0.3m |
0.3m |
0.6m |
||||||
| Multiplication constant |
100 |
100 |
100 |
||||||
| Additive constant |
0 |
0 |
0 |
||||||
| Compensator Type |
Magnetic damping |
Air damping | Magnetic damping |
Magnetic damping |
|||||
| Compensator range |
± 15 ' |
± 15 ' |
± 15 |
||||||
| Compensator setting time |
<2s |
<2s | <2s | <2s | <3s | <1s | <1s | <1s |
<1s |
| Compensator setting accuracy |
± 0.6" |
± 0.6" | ± 0.6" | ± 0.6" | ± 0.3" | ± 0.3" | ± 0.3" | ± 0.3" |
± 0.4" |
| Standard 1 km deviation |
2.5mm |
2.0mm | 1.5mm | 1mm | 1mm | 1mm | 1mm | 1mm |
1.5mm |
| Sensitivity of bubble |
8 /2mm |
8' /2mm |
8 /2mm |
||||||
| Circle graduation |
360 0 or 400 gon (minimum 1 0 or 1 gon) |
||||||||
| Dustproof & waterproof |
IP54 |
IP54 |
IP65 |
||||||
| Working temperature |
-20 0 C 500 C |
-20 0 C 50 0 C |
-30 0 C 50 0 C |
||||||
| Storage temperature |
-40 0 C 700 C |
-400C 700C |
-40 0 C 70 0 C |
||||||
| Net weight per unit |
1.8kg |
1.8kg | 2.0kg | 2.7kg | 2.2kg |
1.9kg |
|||
| Package size (4 PCS/CTN) |
220x420x590mm |
440x320x440mm | 440x320x440mm | 500x360x500mm | 465x340x445mm |
465x340x445mm |
|||
| Gross weight (4 PCS/CTN) |
11kg |
10kg | 12kg | 15kg | 15kg |
14 kg |
|||
